I100X configuration
Once quickAIS is installed, open the application and enter the following information:
- MMSI number - Enter the vessel’s 9 digit MMSI number. The MMSI must be programmed to operate the I100X.
- Vessel name - Enter the name of your vessel.
- Call sign - Enter your vessels call sign.
- Vessel type - Select the type of your vessel.
- Vessel's dimensions - Enter your vessel dimensions to the nearest whole metre, referenced to the location of the I100X.
Figure 5 : QuickAIS layout
| WARNING | |
| Always use a unique MMSI number when setting up the AIS I100X — never duplicate the mothership or any other vessel. Using the same MMSI can cause signal conflicts and tracking errors. |
