Connecting to your NMEA 0183 sensor
NMEA 0183 port 2 is recommended for connecting to your sensor or NMEA 0183 compatible equipment operating at 4,800baud by default. This can be changed using the configuration tools if required. Four wires are provided for a bi-directional connection, and are colour coded as shown in Figure 19.
